Description:
|
A/D conversion method |
Σ-Δ 24bit |
|
Input signal range |
–19.5mV~19.5mV |
|
Load cell excitation |
DC 5V |
|
Max. connection number of load cell |
1~4 |
|
Load cell connection mode |
4 wire |
|
Operating temperature |
-10 °C ~40 °C |
|
Allowable working temperature |
-40 ° C ~ 70 ° C |
|
Wireless transmission frequency |
430MHz to 470MHz |
|
Wireless transmission distance |
200 meters (in wide place) |
|
Dimension
|
100*65*28mm(Include fixed position)
|
Energy conservation
It can not receive the wireless signal from wireless indicator in 1 minute, the system automatically enter to sleep mode for save energy;
The system will automatic wake-up to enter to weighting mode When it receive the wireless signal from indicator in 8 seconds.
Without battery, power supply: DC6~12V
Load cell port:
