Description:
|
A/D conversion method |
Σ-Δ 20bit |
|
Input signal range |
–19.5mV~19.5mV |
|
Load cell excitation |
DC 5V or DC3.3V |
|
Max. connection number of load cell |
1~4 |
|
Load cell connection mode |
4 wire |
|
Operating temperature |
-10 °C ~40 °C |
|
Allowable working temperature |
-40 ° C ~ 70 ° C |
|
Wireless transmission frequency |
430MHz to 470MHz |
|
Wireless transmission distance |
200 meters (in wide place) |
|
Optional power |
DC3.7~12V |
|
Dimension |
70*42*18mm(Without antenna) |
Energy conservation
It can not receive the wireless signal from wireless indicator in 1 minute, the system automatically enter to sleep mode for save energy;
The system will automatic wake-up to enter to weighting mode When it receive the wireless signal from indicator in 8 seconds.
Interface：
|
Group1 |
4 wires |
RED |
E+(loadcell) |
|
BLACK |
E-(loadcell) |
||
|
GREEN |
S+(loadcell) |
||
|
WHITE |
S-(loadcell) |
||
|
Group2 |
2 wires |
RED |
DC3.7-12V + |
|
BLACK |
DC3.7-12V - |
